Veterinary Anesthesia Delivery System for Enhanced Patient Safety

Classification:	Veterinary Anesthesia
Type:	Veterinary Anesthesia
Group:	Veterinary

Send Inquiry

Product Description

Basic Specifications

Model Number IVT-7100E Plus

Weight Specification 29kg

Origin China

Product Details

Gas Supply System

Gas Source: O2, or O2&Air (Option), or O2&N2O (Option)

Pipeline Inlet Pressure: O2: 280kPa ~ 600kPa / 41Psi ~ 87Psi, less than 180L/min. N2O/Air (Option) follows similar specifications.

Safety Features: Release pressure security valve (less than 10kpa), Sound alarm for O2 loss, and N2O cut-off protection.

Flow Meter & Controls

Precision: 2 tubes high precision flow meter (0~1L/min, 1.1~10L/min). Accuracy Level: 2.5.

O2 Flush: 35L/min ~ 75L/min range.

Switching: One Key Switch between rebreath and Non-Rebreath; ACGO Port for Non-Rebreath.

Vaporizer & Respiration

Mounting: Selectatec Mounting Bar for easy replacement.

Compatibility: Supports Isoflurane, Halothane, or Sevoflurane vaporizers.

CO2 Circle Absorber: 800ml Soda Lime Chamber (1600ml option). Features one-key Pop Off valve and APL valve (0.19~6kPa).

Anesthesia Ventilator

Display: 10.1" TFT high-resolution touch screen.

Breath Modes: VCV, PCV, SIMV-VC, SIMV-PC, PSV, Manual/SPONT, SIMV-PRVC (option).

Waveforms: Pressure, Flow rate, Volume, Loop (PV, PF, FV).

Power: Internal Li-ion battery with over 3 hours of operation time.

Technical Parameters

• Tidal Volume: 50 - 1500ml (Option 10-1500ml)

• Respiratory Rate: 1 ~ 100 bpm

• Inspiratory Time: 0.1 ~ 10.0s

• PEEP: OFF, 3 ~ 30 cmH2O

• Pressure Support: 0 ~ 70 cmH2O

• Pressure Control: 5 ~ 70 cmH2O

• Flow Trigger: 0.5 ~ 20L/min

• Monitoring: FiO2, EtCo2, FiCO2, MAC (Options available)

Alarm Settings

Comprehensive alarm system covering: Tidal volume high/low, Minute ventilation high/low, Airway pressure, Apnea, Oxygen deficiency, AC power failure, and Low battery.

Standard Configuration

Anesthesia machine main unit, X60 Anesthesia vaporizer, Adult disposable breath circuit, Pediatric disposable breath circuit, Airbags (0.5L, 1.2L, 3L), and Gas source pipeline (O2/N2O/Air).

Dimensions

Trolley Stand: 55cm * 56cm * 153cm | Weight: 50kg

Frequently Asked Questions

Q: What is the tidal volume range for the IVT-7100E Plus? A: The standard tidal volume range is 50 - 1500ml, with an optional setting available for 10 - 1500ml to accommodate smaller patients.

Q: Does the system include an internal battery for emergencies? A: Yes, it is equipped with a high-capacity Li-ion battery that provides more than 3 hours of continuous working time in case of power failure.

Q: Which ventilation modes are supported by the integrated ventilator? A: It supports a wide range of modes including VCV, PCV, SIMV-VC, SIMV-PC, PSV, Manual/SPONT, and an optional SIMV-PRVC mode.

Q: Can I use different types of anesthetic agents with this machine? A: Yes, the Selectatec Mounting Bar allows for easy installation and switching between Isoflurane, Halothane, and Sevoflurane vaporizers.

Q: Is the display easy to read during surgery? A: Absolutely. The unit features a large 10.1-inch TFT touch screen that displays waveforms for pressure, flow rate, and volume simultaneously.

Q: What safety alarms are included in the system? A: The system monitors and alerts for tidal volume, minute ventilation, respiratory rate, airway pressure (high/low), apnea, oxygen deficiency, and power status.
